ABB S200M miniature circuit breaker
ABB S200M miniature circuit breaker, 3 pole, D-curve, 2 A, 10 kA (IEC/EN 60898-1).
Product specification
S203M-D2
ABB S200M miniature circuit breaker, 3 pole, D-curve, 2 A, 10 kA (IEC/EN 60898-1).
Dimensions & specifications
| Manufacturer | ABB |
|---|---|
| ABB order code | 2CDS273001R0021 |
| Series | S200M |
| Poles | 3 |
| Tripping characteristic | D |
| Rated current | 2 A |
| Breaking capacity (EN 60898-1) | 10 kA |
| Rated voltage | 400 V AC |
| Width | 52.5 mm |
| Height | 88 mm |
| Depth | 69 mm |
Siemens 5SY4 and ABB S200M models are rated 10 kA (EN 60898-1). Four-pole models are 4P, not 3P+N.
