Control Gear
Motor control, circuit protection and isolation. Choose a product, then select its specification and matching accessories.
Contactors
Select manufacturer, motor rating and coil supply
Browse range
MPCBs
0.35–80 A · S00, S0 and S2
Browse range
Soft Starters
3RW30 / 3RW40 · 1.5–55 kW · with or without overload protection
Browse range
MCBs
2–63 A · B/C/D curves · 1–4 pole
Browse range
Isolators
16–125 A · front or door-coupled
Browse range
MCCBs
40–160 A · 3/4 pole · 36/55 kA
Browse range
Thermal overload relays
Select relay range and motor current setting
Browse range
Plug-in Relays
Omron G2R-2 · MY4 · matched bases
Browse range
Accessories
Browse accessories for this product group. Select a main part to see its matched options.
Browse rangeSearch part numbers & specifications
Open to search 681 parts.
Browse part numbers (681)
- 3RT2015-1BB41SIRIUS S00 power contactor, 3 kW at 400 V, 7 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO, screw terminals.
- 3RT2015-1AB01SIRIUS S00 power contactor, 3 kW at 400 V, 7 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2015-1AF01SIRIUS S00 power contactor, 3 kW at 400 V, 7 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2015-1AP01SIRIUS S00 power contactor, 3 kW at 400 V, 7 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2016-1BB41SIRIUS S00 power contactor, 4 kW at 400 V, 9 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO, screw terminals.
- 3RT2016-1AB01SIRIUS S00 power contactor, 4 kW at 400 V, 9 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2016-1AF01SIRIUS S00 power contactor, 4 kW at 400 V, 9 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2016-1AP01SIRIUS S00 power contactor, 4 kW at 400 V, 9 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2017-1BB41SIRIUS S00 power contactor, 5.5 kW at 400 V, 12 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO, screw terminals.
- 3RT2017-1AB01SIRIUS S00 power contactor, 5.5 kW at 400 V, 12 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2017-1AF01SIRIUS S00 power contactor, 5.5 kW at 400 V, 12 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2017-1AP01SIRIUS S00 power contactor, 5.5 kW at 400 V, 12 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2018-1BB41SIRIUS S00 power contactor, 7.5 kW at 400 V, 16 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO, screw terminals.
- 3RT2018-1AB01SIRIUS S00 power contactor, 7.5 kW at 400 V, 16 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2018-1AF01SIRIUS S00 power contactor, 7.5 kW at 400 V, 16 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2018-1AP01SIRIUS S00 power contactor, 7.5 kW at 400 V, 16 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO, screw terminals.
- 3RT2026-1BB40SIRIUS S0 power contactor, 11 kW at 400 V, 25 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO + 1 NC, screw terminals.
- 3RT2026-1AC20SIRIUS S0 power contactor, 11 kW at 400 V, 25 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2026-1AG20SIRIUS S0 power contactor, 11 kW at 400 V, 25 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2026-1AL20SIRIUS S0 power contactor, 11 kW at 400 V, 25 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2027-1BB40SIRIUS S0 power contactor, 15 kW at 400 V, 32 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO + 1 NC, screw terminals.
- 3RT2027-1AC20SIRIUS S0 power contactor, 15 kW at 400 V, 32 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2027-1AG20SIRIUS S0 power contactor, 15 kW at 400 V, 32 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2027-1AL20SIRIUS S0 power contactor, 15 kW at 400 V, 32 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2028-1BB40SIRIUS S0 power contactor, 18.5 kW at 400 V, 38 A AC-3 / AC-3e, 3 pole. 24 V DC coil, 1 NO + 1 NC, screw terminals.
- 3RT2028-1AC20SIRIUS S0 power contactor, 18.5 kW at 400 V, 38 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2028-1AG20SIRIUS S0 power contactor, 18.5 kW at 400 V, 38 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2028-1AL20SIRIUS S0 power contactor, 18.5 kW at 400 V, 38 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2036-1NB30SIRIUS S2 power contactor, 22 kW at 400 V, 51 A AC-3 / AC-3e, 3 pole. 20–33 V AC/DC (includes 24 V DC) coil, 1 NO + 1 NC, screw terminals.
- 3RT2036-1AC20SIRIUS S2 power contactor, 22 kW at 400 V, 51 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2036-1AG20SIRIUS S2 power contactor, 22 kW at 400 V, 51 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2036-1AL20SIRIUS S2 power contactor, 22 kW at 400 V, 51 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2037-1NB30SIRIUS S2 power contactor, 30 kW at 400 V, 65 A AC-3 / AC-3e, 3 pole. 20–33 V AC/DC (includes 24 V DC) coil, 1 NO + 1 NC, screw terminals.
- 3RT2037-1AC20SIRIUS S2 power contactor, 30 kW at 400 V, 65 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2037-1AG20SIRIUS S2 power contactor, 30 kW at 400 V, 65 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2037-1AL20SIRIUS S2 power contactor, 30 kW at 400 V, 65 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2038-1NB30SIRIUS S2 power contactor, 37 kW at 400 V, 80 A AC-3 / AC-3e, 3 pole. 20–33 V AC/DC (includes 24 V DC) coil, 1 NO + 1 NC, screw terminals.
- 3RT2038-1AC20SIRIUS S2 power contactor, 37 kW at 400 V, 80 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2038-1AG20SIRIUS S2 power contactor, 37 kW at 400 V, 80 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2038-1AL20SIRIUS S2 power contactor, 37 kW at 400 V, 80 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2046-1NB30SIRIUS S3 power contactor, 45 kW at 400 V, 95 A AC-3 / AC-3e, 3 pole. 20–33 V AC/DC (includes 24 V DC) coil, 1 NO + 1 NC, screw terminals.
- 3RT2046-1AC20SIRIUS S3 power contactor, 45 kW at 400 V, 95 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2046-1AG20SIRIUS S3 power contactor, 45 kW at 400 V, 95 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2046-1AL20SIRIUS S3 power contactor, 45 kW at 400 V, 95 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2047-1NB30SIRIUS S3 power contactor, 55 kW at 400 V, 110 A AC-3 / AC-3e, 3 pole. 20–33 V AC/DC (includes 24 V DC) coil, 1 NO + 1 NC, screw terminals.
- 3RT2047-1AC20SIRIUS S3 power contactor, 55 kW at 400 V, 110 A AC-3 / AC-3e, 3 pole. 24 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2047-1AG20SIRIUS S3 power contactor, 55 kW at 400 V, 110 A AC-3 / AC-3e, 3 pole. 110 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
- 3RT2047-1AL20SIRIUS S3 power contactor, 55 kW at 400 V, 110 A AC-3 / AC-3e, 3 pole. 230 V AC, 50/60 Hz coil, 1 NO + 1 NC, screw terminals.
