Siemens SIRIUS S0 motor protection circuit breaker
3RV2021-4CA10
SIRIUS S0 motor protection circuit breaker, 16–22 A adjustable thermal setting, class 10, screw terminals.
- Frame size
- S0
- Current setting range
- 16–22 A
Product specification
3RV2021-4CA10
SIRIUS S0 motor protection circuit breaker, 16–22 A adjustable thermal setting, class 10, screw terminals.
Dimensions & specifications
Choose the setting range to suit the motor nameplate current.
Accessories & related parts
3RV2021-4CA10 — specifications & documents
SIRIUS S0 motor protection circuit breaker, 16–22 A adjustable thermal setting, class 10, screw terminals.
| Thermal setting range | 16–22 A |
|---|---|
| Trip class | 10 |
| Size | S0 |
| Connection | Screw terminals |
| Instantaneous release | 286 A |
Related parts
- 3RV2901-1A SIRIUS auxiliary switch, 1 NO + 1 NC, left side mounting, screw terminals. For 3RV2 motor protection circuit breakers, sizes S00–S3.
- 3RV2901-1E SIRIUS auxiliary switch, 1 NO + 1 NC, front / transverse mounting, screw terminals. For 3RV2 motor protection circuit breakers, sizes S00–S3.
- 3RV2901-1B SIRIUS auxiliary switch, 2 NO, left side mounting, screw terminals. For 3RV2 sizes S00–S3.
- 3RV2901-1C SIRIUS auxiliary switch, 2 NC, left side mounting, screw terminals. For 3RV2 sizes S00–S3.
- 3RV2901-1D SIRIUS auxiliary switch, 1 CO, front / transverse mounting, screw terminals. For 3RV2 sizes S00–S3.
- 3RV2901-1F SIRIUS auxiliary switch, 2 NO, front / transverse mounting, screw terminals. For 3RV2 sizes S00–S3.
- 3RV2926-1B SIRIUS door-coupling rotary operating mechanism, grey, 130 mm shaft, for 3RV2 sizes S00–S3.
- 3RV2926-1K SIRIUS door-coupling rotary operating mechanism, grey, 330 mm shaft, for 3RV2 sizes S00–S3.
- 3RV2926-1C SIRIUS door-coupling rotary operating mechanism, red / yellow, 130 mm shaft, for 3RV2 sizes S00–S3.
- 3RV2926-1L SIRIUS door-coupling rotary operating mechanism, red / yellow, 330 mm shaft, for 3RV2 sizes S00–S3.
- 3RV2902-1AB4 SIRIUS undervoltage release, 24 V DC, right-side mounting for 3RV2 sizes S00–S3.
- 3RV2902-1AP0 SIRIUS undervoltage release, 230 V AC 50 Hz / 240 V AC 60 Hz, right-side mounting for 3RV2 sizes S00–S3.
- 3RV2902-1DB0 SIRIUS shunt release, 20–24 V AC, 50/60 Hz continuous duty or 20–70 V AC/DC for maximum 5 seconds, right-side mounting for 3RV2 sizes S00–S3.
- 3RV2902-1DP0 SIRIUS shunt release, 210–240 V AC, 50/60 Hz continuous duty or 190–330 V AC/DC for maximum 5 seconds, right-side mounting for 3RV2 sizes S00–S3.
- 3RV1915-1AB SIRIUS three-phase busbar for 2 screw-terminal S00 / S0 motor protection breakers, 45 mm pitch, 63 A.
- 3RV1915-1BB SIRIUS three-phase busbar for 3 screw-terminal S00 / S0 motor protection breakers, 45 mm pitch, 63 A.
- 3RV1915-1CB SIRIUS three-phase busbar for 4 screw-terminal S00 / S0 motor protection breakers, 45 mm pitch, 63 A.
- 3RV1915-1DB SIRIUS three-phase busbar for 5 screw-terminal S00 / S0 motor protection breakers, 45 mm pitch, 63 A.
- 3RV1915-2AB SIRIUS three-phase busbar for 2 screw-terminal S00 / S0 motor protection breakers, 55 mm pitch, 63 A.
- 3RV1915-2BB SIRIUS three-phase busbar for 3 screw-terminal S00 / S0 motor protection breakers, 55 mm pitch, 63 A.
- 3RV1915-2CB SIRIUS three-phase busbar for 4 screw-terminal S00 / S0 motor protection breakers, 55 mm pitch, 63 A.
- 3RV1915-2DB SIRIUS three-phase busbar for 5 screw-terminal S00 / S0 motor protection breakers, 55 mm pitch, 63 A.
- 3RV1915-3AB SIRIUS three-phase busbar for 2 screw-terminal S00 / S0 motor protection breakers, 63 mm pitch, 63 A.
- 3RV1915-3CB SIRIUS three-phase busbar for 4 screw-terminal S00 / S0 motor protection breakers, 63 mm pitch, 63 A.
