ERICO 4-way copper earth bar
EEB04C506D1A
4-way copper earth bar, one disconnecting link, M10 terminals, 375 mm long.
- Connections
- 4 way
- Disconnecting links
- 1 link
Product specification
EEB04C506D1A
4-way copper earth bar, one disconnecting link, M10 terminals, 375 mm long.
Dimensions & specifications
Overall dimensions and copper-bar dimensions are shown separately. Choose cable terminations and bonding conductors to suit the installation design.
Accessories & related parts
EEB04C506D1A — specifications & documents
4-way copper earth bar, one disconnecting link, M10 terminals, 375 mm long.
| Range | Electrical Earth Bar |
|---|---|
| Connections | 4 |
| Disconnecting links | 1 |
| Terminal thread | M10 |
| Length | 375 mm |
| Overall width | 100 mm |
| Height | 94 mm |
| Copper bar width | 50 mm |
| Copper thickness | 6 mm |
| Bar material | Bare copper |
| Insulator material | Polyamide |
| Hardware | Stainless steel EN 1.4401 |
| Mounting brackets | Included |
