WISKA GLP25 black
10106657
GLP25 black, M25 × 1.5 polyamide stuffing glands with locknuts. 9–17 mm cable range. Pack of 10.
- Product type
- Polyamide stuffing glands
- Thread size
- M25
- Colour
- Black
Product specification
10106657
GLP25 black, M25 × 1.5 polyamide stuffing glands with locknuts. 9–17 mm cable range. Pack of 10.
Dimensions & specifications
Select against the cable outside diameter. Quantities are individual glands or packs as shown with the part. BW and CW are for SWA; CXT is for wire-braided cable.
Accessories & related parts
10106657 — specifications & documents
GLP25 black, M25 × 1.5 polyamide stuffing glands with locknuts. 9–17 mm cable range. Pack of 10.
| Manufacturer type | GLP25 black |
|---|---|
| Manufacturer order number | 10106657 |
| Thread | M25 × 1.5 |
| Thread length | 10 mm |
| Protection class | IP68 (5 bar 30 min), IP69 |
| Material | Polyamide |
| Pack quantity | 10 |
| Quote quantity basis | Packs of 10 |
| Cable clamping range | 9–17 mm |
| Colour | Black · RAL 9005 |
| Seal material | EPDM |
| Pack contents | 10 glands and 10 locknuts |
| Temperature range | -40 °C to 100 °C |
| UK product number | 99705 |
